<div>Welcome to our store! We hope you have a wonderful shopping experience!</div>

<ul><li>Feature:
1. It adopts DIN rail type installation, which is convenient and quick to install.
2. Advanced isolated power supply ensures its stablity and reliability, and the continuous working power supply varies between 110V~240V ADC.
3. Digital temperature controller has delay protection and power‑down memory protection function.
4. The temperature sensor line can be connected to the ordinary line for 100 meters.
5. Temperature regulator can set parameters to save long‑term memory of power failure.
Specification:
Item Type: Temperature Controller
Model: TMC-6000
Material: ABS
Power Supply: DC /AC 110-240V
Uses: used in various cooling and heating scenes
Power: 2W
Button: Push-type membrane keyboard
Input: One-way (10K) NTC thermistor temperature sensor output, measuring range -50°C to 120°C
Output:
1. One-way relay NO touch point is used for cooling output, and NC contact is used for heating output.
2. The current capacity of the output contact is limited to 5A for load and 1A for inductive load. It can control 1000W electric heating or 200W electric motor or water pump. An AC contactor is needed to expand the capacity to obtain a larger load.
Working Temperature: -10°C to 50°C
Measuring Range: -50°C to 120°C
Setting Range: minimum limit: -45°C to control the temperature, maximum limit: control temperature to 110°C
Control Range: -45~110°C
Temperature Control Return Difference: 1~30°C
Delay Time: 0~300S
Deviation Correction: -25~25°C .
Package List:
1 x Temperature Controller1 x NTC (10K) Temperature Sensor Line 1 x User Manual
Note:
The maximum load current is 10A, please ensure the allowable value (about 6A) during long‑term use to increase the use time. The parameters and settings in the user manual are the parameters when the load is connected to the NO terminal. If you need to connect to the NC side, please set it accordingly.</li></ul>
