<div>Welcome to our store! We hope you have a wonderful shopping experience!</div>

<ul><li>All inclusive oblique insertion Slimline SFF-8654 8i 74Pin PCI-E to Dual 2X OCulink 8611 4i Server graphics card cable
Cable Length: 0.5M; Wire Size: 32AWG, Tinned Copper, OD: 0. 9 x 2.3,MM; Lock to Mating Part: With Latch; Plating: Au 15u' min over Ni 100u' min; Environmental Compliance: ROHS; Flammability: Cable Horizontal flame, PCB 94V-0, PBT 94V-0
Applications: Data/Communications, RAID (Redundant Array of Independent Disks), Workstations, Rack-mount server, Servers, Storage rack
Transmission rate 12Gbps.
Meet SAS4.0 specification.
Mechanical Performance
Mating Force and Unmating Force
Condition: EIA 364-13. Insert and extract at a speed of 25mm/minute.
Mating Force: 55 N maximum for Mini SAS.
Unmating Force: 49 N maximum for Mini SAS.
Mating Force: 45 N maximum for SATA connector.
Unmating Force: 10 N maximum for SATA connector.
Electrical Performance
Contact Current Rating, 0.5Amperes maximum per pin when mated.
Voltage Rating, 32VAC per contact when mated or unmated.
Contact Resistance, 32mohm max. initial, 15mohm maximum after stress test.
Dielectric Withstanding Voltage, 500 VAC for 1 minute no breakdown.
Insulation Resistance, 1000 Mohm minimum.
Signal Integrity
1. Mated Connector Impedance: 85 ohm±15%
2. Cable Absolute Impedance: 85 ohm±10%
3. Cable Pair Matching: ±5 ohm
4. Common Mode Impedance: 25 to 40 ohms
5. Insertion loss: -6dB maximum up to 4.5Ghz;
6. Crosstalk: -26 dB up to 6Ghz;
Product Environmental Compliance
RoHS2.0: Compliant
China RoHS: Yes
REACH SVHC: Yes
Low-Halogen Status: Not Reviewed
Color: Black
Material: plastic
Package Contents:
1 * Adapter Cable
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.</li></ul>

Condición

Material

País de Origen

Ancho del Producto Ensamblado

Gama Color

Peso del Producto Ensamblado

Contenido del Empaque

Longitud del Producto Ensamblado

Altura del Producto Ensamblado

Marca

PCI-E Slimline SAS Inclusive Scoop-Proof Anti-Misplug SFF-8654 8i 74P to SFF-8639 U.2 + 15P with Right Left Screw Holes
