<div>Welcome to our store! We hope you have a wonderful shopping experience!</div>

<ul><li>Specification:
[vS] Red line, drive voltage, DC+310V (220V AC is 310V DC after connected to the rectifier bridge, and it is better to add a 100uf/400V filter capacitor). This time, the wide voltage of the motor is DC176V-375V, that is, it can be used after rectified with AC 110V-220V.
[GND] Black wire, the negative pole of all power supplies are connected together.
[Vcc] White wire, working voltage, DC14-16V
[Vsp] Yellow line, speed control, 0-6.5VPWM speed regulation, the lower the voltage
The slower the speed, the better the mediation
[FG] Blue line, speed feedback
[Note]: This motor is a 220V motor. It does not generate 220V power. The following is a picture of power generation. It is simpler to generate power: connect the red and black wires. Both the positive and negative rotation can generate power. With LED lights, you do not need to connect anything. With others, you need to rectify and stabilize the voltage. DIY is made by yourself
Power generation is the generation of direct current
Approximate power generation parameters:
120 rpm: 9v
240 rpm: 18V
480 rpm: 36V
960 rpm: 72V
Product includes:
1 x Brushless Generator</li></ul>

Marca

Peso del Producto Ensamblado

FabricanteNombre del Fabricante

Dimensiones del producto ensamblado

Diy 9v-72v Brushless Motor For 3phase Wind Turbine Generator Windmill Hand Crank

Specification:
[vS] Red line, drive voltage, DC+310V (220V AC is 310V DC after connected to the rectifier bridge, and it is better to add a 100uf/400V filter capacitor). This time, the wide voltage of the motor is DC176V-375V, that is, it can be used after rectified with AC 110V-220V.
[GND] Black wire, the negative pole of all power supplies are connected together.
[Vcc] White wire, working voltage, DC14-16V
[Vsp] Yellow line, speed control, 0-6.5VPWM speed regulation, the lower the voltage
The slower the speed, the better the mediation
[FG] Blue line, speed feedback
[Note]: This motor is a 220V motor. It does not generate 220V power. The following is a picture of power generation. It is simpler to generate power: connect the red and black wires. Both the positive and negative rotation can generate power. With LED lights, you do not need to connect anything. With others, you need to rectify and stabilize the voltage. DIY is made by yourself
Power generation is the generation of direct current
Approximate power generation parameters:
120 rpm: 9v
240 rpm: 18V
480 rpm: 36V
960 rpm: 72V
Product includes:
1 x Brushless Generator
