<div>Welcome to our store! We hope you have a wonderful shopping experience!</div>

<ul><li>Features:
1: Product model: 24 functions to meet more application requirements, it can control solenoid valves, water pumps, motors, lightstrips, etc.
2: Input voltage: DC 5/6/12/24V optional
3:Output power: can control DC or AC load within 5 A
4: Time range:0.01 second to 999 minutes. adjustable
Wiring port
1. DC+: Input the positive pole of the DC power supply
2.DC-: Input the negative pole ofDC power supply
3.IN+: Positive signal input terminal
4.IN-: negative signal input terminal
5. NO: Relay normally open interface, the relay is suspended before it is closed, and shorted to COM after it is closed
6.CO: common interface of relay7. NC: Normally closed interface of the relay, the relay is short-conmected with CO before it is closed, and it is suspended afterbeing closed
Button trigger. (positive trigger: DC- and in- short-circuit, DC+ and IN+ are conmected to the button)Or. (Negative trigger: DC+ and in+ are short-circuited, DC- and IN- are connected to the button)</li></ul>

Dimensiones del producto ensamblado

DC 5V 12V Delay Turn On/Off Cycle Signal Trigger Timer Relay Switch Board jy

Devolución hasta 30 días después de recibido.

Features:
1: Product model: 24 functions to meet more application requirements, it can control solenoid valves, water pumps, motors, lightstrips, etc.
2: Input voltage: DC 5/6/12/24V optional
3:Output power: can control DC or AC load within 5 A
4: Time range:0.01 second to 999 minutes. adjustable
Wiring port
1. DC+: Input the positive pole of the DC power supply
2.DC-: Input the negative pole ofDC power supply
3.IN+: Positive signal input terminal
4.IN-: negative signal input terminal
5. NO: Relay normally open interface, the relay is suspended before it is closed, and shorted to COM after it is closed
6.CO: common interface of relay7. NC: Normally closed interface of the relay, the relay is short-conmected with CO before it is closed, and it is suspended afterbeing closed
Button trigger. (positive trigger: DC- and in- short-circuit, DC+ and IN+ are conmected to the button)Or. (Negative trigger: DC+ and in+ are short-circuited, DC- and IN- are connected to the button)
