<ul><li>Feature:
1. Easy Switching: 2 position design enables light rotation for switching as well as accurate positioning.
2. Stable Working: The 4 way air valve has large effective circulation area to ensure small pressure loss.
3. Secure Sealing: High accuracy valve stem promises perfect matching and good air tightness for sealing.
4. Practical Uses: Allows for broad application in automatic production, industrial equipment and so on.
5. Good Durability: Through special process, the inner hole has low friction resistance and long service life.
Specification:
Item Type: Air Hand Valve
Material: Aluminium Alloy
Model
4HV310-08
4HV310-10
Working Method
Air
Tube Calibre
G1/4
G3/8
Effective Cross Sectional Area
30mm² (Cv=4.89)
33mm² (Cv=5.27)
Number of Position
2 Position 4 Way
Lubricating
No Lubricating Required
Operating Pressure Range
0-1.0MPa(0-145psi)
Proof Pressure
1.5MPa(215psi)
Operating Temperature
-20-70℃
Working Angle
90°
.
Package List:
1 x Air Hand Valve1 x Handle
Note:
Keep the pipeline clean to prolong the service life.</li></ul>

Condición

Material

País de Origen

Ancho del Producto Ensamblado

Gama Color

Peso del Producto Ensamblado

Contenido del Empaque

Longitud del Producto Ensamblado

Altura del Producto Ensamblado

Marca

2 Position 4 Way Rotary Lever Manual Pneumatic Valve Pneumatic Flow Control Switch Accessory 4HV310-10

Feature:
1. Easy Switching: 2 position design enables light rotation for switching as well as accurate positioning.
2. Stable Working: The 4 way air valve has large effective circulation area to ensure small pressure loss.
3. Secure Sealing: High accuracy valve stem promises perfect matching and good air tightness for sealing.
4. Practical Uses: Allows for broad application in automatic production, industrial equipment and so on.
5. Good Durability: Through special process, the inner hole has low friction resistance and long service life.
Specification:
Item Type: Air Hand Valve
Material: Aluminium Alloy
Model
4HV310-08
4HV310-10
Working Method
Air
Tube Calibre
G1/4
G3/8
Effective Cross Sectional Area
30mm² (Cv=4.89)
33mm² (Cv=5.27)
Number of Position
2 Position 4 Way
Lubricating
No Lubricating Required
Operating Pressure Range
0-1.0MPa(0-145psi)
Proof Pressure
1.5MPa(215psi)
Operating Temperature
-20-70℃
Working Angle
90°
.
Package List:
1 x Air Hand Valve1 x Handle
Note:
Keep the pipeline clean to prolong the service life.
