<div>Welcome to our store! We hope you have a wonderful shopping experience!</div>

<ul><li>Hall effect current sensor
No voltage drop and heat on current sensor components
Offset and Sensitivity are calibrated in factory
Made of high-quality materials, sturdy and
Easy to use
Offset and sensitivity are factory calibrated
Continuous current rating: 0~150A DC
Sensitivity: 20mV/A, INAV/ ratio = 200, BATT_AMP_PERVLT = 50
VBAT voltage sensing: 0~69V, INAV ratio = 2100, ratio = 210, BATT_VOLT_MULT = 21.0
Power consumption: 17mA
Voltage offset error at zero current: +-10mV
Current output voltage error: 5%
Operating temperature: -30~80 °C
Vbat: for voltage sensing, supports 0~69V IN
Voltage: = 1/21 Vbat, 0~3.3V output
Current: current signal, 0~3.3V output
5V: -150A board power supply, supports 4~13V Input, 17mA
G: GND
TX/RX: For firmware update and configuration (to be supported)
Tip: Hall sensor should be installed away from iron and magnetic materials
(Due to different batches, the printed words on the product be different, which does not affect use)
Material: PCB
colour: As shown
Package Contents:
1 x Hall Current Sensor
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.</li></ul>

Condición

Material

País de Origen

Ancho del Producto Ensamblado

Gama Color

Peso del Producto Ensamblado

Contenido del Empaque

Longitud del Producto Ensamblado

Altura del Producto Ensamblado

Marca

150A Hall Current Sensor -150A for FPV Flight Controller RC

Hall effect current sensor
No voltage drop and heat on current sensor components
Offset and Sensitivity are calibrated in factory
Made of high-quality materials, sturdy and
Easy to use
Offset and sensitivity are factory calibrated
Continuous current rating: 0~150A DC
Sensitivity: 20mV/A, INAV/ ratio = 200, BATT_AMP_PERVLT = 50
VBAT voltage sensing: 0~69V, INAV ratio = 2100, ratio = 210, BATT_VOLT_MULT = 21.0
Power consumption: 17mA
Voltage offset error at zero current: +-10mV
Current output voltage error: 5%
Operating temperature: -30~80 °C
Vbat: for voltage sensing, supports 0~69V IN
Voltage: = 1/21 Vbat, 0~3.3V output
Current: current signal, 0~3.3V output
5V: -150A board power supply, supports 4~13V Input, 17mA
G: GND
TX/RX: For firmware update and configuration (to be supported)
Tip: Hall sensor should be installed away from iron and magnetic materials
(Due to different batches, the printed words on the product be different, which does not affect use)
Material: PCB
colour: As shown
Package Contents:
1 x Hall Current Sensor
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
